Convert Serial to GPRS 3G GSM Modem The Perfect Solution for PLC AMR Data Collection

Model Number : BGT-2103

Place of Origin : Beijing, China

Brand Name : BGT

Product name : gsm rtu sms controller

Cellular Module : Industrial cellular module

Standard and Band : Support:TDD-LTE,FDD-LTE,EVDO,WCDMA,TD-SCDMA,CDMA1X,GPRS/EDGE

TX power : <24dBm

RX sensitivity : <109dBm

CPU : Industrial 16/32 bits CPU

FLASH : 512KB (Extendable)

SRAM : 256KB(Extendable)

Indicator : "Power","ACT","Online"

Antenna : Standard SMA female interface, 50 ohm, lighting protection(optional)

Packaging Details : Box

Port : Tianjin

Supply Ability : 2000 Piece/Pieces per Week

Price : $99.00 - $299.00/pieces

MOQ : 1 piece

Contact Now

What We Sell

Convert Serial to GPRS 3G GSM Modem The Perfect Solution for PLC AMR Data Collection

WCDMA/HSDPA/HSUPA IP MODEM

F2414 WCDMA/HSDPA/HSUPA IP MODEM is a kind of cellular terminal device that provides data transfer function by public WCDMA/HSDPA/HSUPA network.
It adopts high-powered industrial 32 bits CPU and embedded real time operating system. It supports RS232 and RS485 (or RS422) port that can conveniently and transparently connect one device to a cellular network, allowing you to connect to your existing serial devices with only basic configuration. It has low power consumption states in which the power consumption could be 1ower than 1mA@12VDC. It has compatible digital I/O channel, ADC, input pulse counter and pulse wave output function.
It has been widely used on M2M fields, such as intelligent transportation, smart grid, industrial automation, telemetry, finance, POS, water supply, environment protection, post, weather, and so on.

Design for Industrial Application

*High-powered industrial cellular module

*High-powered industrial 32 bits CPU
*Low power consumption design,support muti-sleep and trigger modes to reduce the power dissipation farthest.
*Housing:iron,providing IP30 protection.
*Power range:DC 5~35V

Stability and Reliability

*Support hardware and software WDT
*Support auto recovery mechanism to make the data end always online.
*RS232/RS485/RS422 ports:15KV ESD protection

*SIM/UIM port:15KV ESD protection
*Power port:reverse-voltage and over-voltage protection
*Antena port:lighting protection(optional)

Standard and Convenientce

*Adopt terminal block interface, convenient for industrial application

*Support standard RS232/RS485 ports that can connect to serial devices directly
*TTL logic level RS232 interface can be customized

*Support intellectual mode, enter into communication state automatically when powered
*Provide management software for remote management
*Support several work modes
*Convenient configuration and maintenance interface

High-performance

*Support hardware and software WDT
*Support auto recovery mechanism, including online detect, auto redial when offline to make it always online

*RS232/RS485/RS422 port: 15KV ESD protection
*SIM/UIM port: 15KV ESD protection
*Power port: reverse-voltage and overvoltage protection
*Antenna port: lightning protection(optional)

Product specification

Item	Content
Cellular Module	Industrial cellular module
Standard and Band	UMTS/WCDMA/HSDPA/HSUPA 850/1900/2100MHz, 850/900/1900/2100MHz(optional) GSM 850/900/1800/1900MHz WCDMA/HSDPA/HSUPA/EDGE CLASS 12
Standard Power	DC 12V/0.5A
Power Range	DC 5~35V
Housing	Iron,providing IP30 protection
Dimensions	91x58.5x22 mm
Weight	205g
Operating Temperature	-35~+75ºC（-22~+167℉）
Storage Temperature	-40~+85ºC（-40~+185℉）
Operating Humidity	95%(unfreezing)

Appliction

Energy Sufficiency

Commerical & industrial metering

Distribution Automation

Renewable Energy

Realated Products

Company Profile

EXS&CES

Produce &Package

Advantages& FAQ

Advantages:

Innovation: All Products have proprietary intellectual property rights

Brand: The main products are the No.1 in the flood monitoring equipment industry

Standard: The only one company who participates in making the national standard in the hydraulic engineering industry.

Market Share : Our main products have top 3 market share in China and have sold our products to more than 28 provinces, 500 counties.

FAQ

Q1. Can I have a sample order ?

A: Yes, we welcome sample order to test and check quality.Mixed samples are acceptable.

Q2. What about the lead time?

A:Sample needs 3-5 days, mass production time needs 1-2 weeks for order quantity more than

Q3. Do you have any MOQ limit?

A: Low MOQ, 1pc for sample checking is available

Q4. How do you ship the goods and how long does it take to arrive?

A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.

Q5. How to proceed an order ?

A: Firstly let us know your requirements or application.Secondly We quote according to your requirements or our suggestions.Thirdly customer confirms the samples and places deposit for formal order.Fourthly We arrange the production.

Q6. Is it OK to print my logo on the products?

A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.

Q7: Do you offer guarantee for the products?

A: Yes, we offer 2-5 years warranty to our products.

Q8: How to deal with the faulty?

A: Firstly, Our products are produced in strict quality control system and the defective rate will be less
than 0.2%.Secondly, during the guarantee period, we will send new one with new order for small quantity. For defective batch products, we will repair them and resend them to you or we can discuss the solution including re-call according to real situation.
