Reed Switch Output WS-601 0.2mm Rainfall Measurement Sensor for Environment Monitoring

Warranty : 1year

Customized support : OEM, ODM

Place of Origin : Beijing, China

Brand Name : BGT

Model Number : WS-601SS2

Product name : 0.2mm rainfall measurement steel stainless tipping bucket rain gauge

Inner Diameter : 200mm(8 inch)

Resolution : 0.2mm

Measuring range : ≤4mm/min

Bucket : ABS UV Stabilished plastic bucket

Accuracy : ±≤ 4%

Output : Reed switch, 5 purlse/mm

Material : Stainless Steel

Operating Temperature : -10℃~50℃

Weight : 3.8kg

Packaging Details : Cartons

Price : $128.80/pieces 1-9 pieces

MOQ : 1 piece

Contact Now

Please Attention

Reed Switch Output WS-601 0.2mm Rainfall Measurement Sensor for Environment Monitoring

Beijing Guoxinhuayuan Technology Co.,Ltd OFFER YOU:

1.Factory direct price.
2.Nice quality.
3.Small order is welcome.
4.Online payment.
5.Refund money in case of bad quality.
6.Sample offered but you need to pay it.
7.1 year free repair for quality warranty.

Product Description

_{WS-601SS2 Tipping Bucket Rain Gauge}

Tipping Bucket Rain Gauge is a durable weather instrument for monitoring rain rate and total rainfall. It has been updated and improved with the addition of an inner funnel to even the flow of the rainfall into the gauge, providing better accuracy at higher rainfall rates. With minimal care it will provide many years of service. The rain gauge is constructed of high impact UV-protected plastic/ stainless steel to provide reliable, low-cost tipping bucket rainfall monitoring. The tipping bucket sensor mechanism activates a sealed reed switch that produces a contact closure for each 0.1mm, 0.2 mm or 0.5mm of rainfall. The rain gauge sensor can be pole mounted or bolted to a level plate.

Features

WMO standard bucket's top diameter (200mm/8")

High Accuracy

Good stability

Low resistance

Mesh in the funnel preventing debris

Highly polished stainless steel construction

Horizontal Bubble in bottom

Application

Environmental monitoring

Water supply system

Hydrological monitoring

Natural disaster monitoring

Climate research

Weather monitoring stations

Smart Agriculture

1.Stainless Steel Enclosure assembly (Body)

2.Stainless Steel Funnel

3.Aluminum Bracket

4.Stainless Steel Tips

5.Reed switch.

6. Stainless Steel Discharge holder

7. Stainless Steel Mounting foot

8. Bull-eye Level

Acute angle of cutting edge	40°~45°
inner diameter	Φ200+0.6mm
0.2gle -tip	0.2mm
Measuring range	≤4mm/min
Accuracy	±≤ 2%(≤ 0.4mm/min); ±≤ 4% (≤4mm/min);
Tips	ABS UV Stabilished plastic Tips
Material	SS304
Humidity	95%
Operating Temperature	-10℃~50℃
Discharge Control	Drain out straightly by flow mechanism
Level Control	Bull-eye level fitted on base
Mounting holes	Three mountings
Weight	3.6kg
Height	330mm
Packing size	310310460(MM)

Appliction

Company Profile

EXS&CES

Produce &Package

Advantages& FAQ

Advantages:

Innovation: All Products have proprietary intellectual property rights

Brand: The main products are the No.1 in the flood monitoring equipment industry

Standard: The only one company who participates in making the national standard in the hydraulic engineering industry.0.2mm rainfall measurement used steel stainless tipping bucket rain gauge

Market Share : Our main products have top 3 market share in China and have sold our products to more than 28 provinces, 500 counties.

FAQ0.2mm rainfall measurement used steel stainless tipping bucket rain gauge

Q1. Can I have a sample order ?
0.2mm rainfall measurement used steel stainless tipping bucket rain gauge
A: Yes, we welcome sample order to test and check quality.Mixed samples are acceptable.
0.2mm rainfall measurement used steel stainless tipping bucket rain gauge
Q2. What about the lead time?

A:Sample needs 3-5 days, mass production time needs 1-2 weeks for order quantity more than

Q3. Do you have any MOQ limit?

A: Low MOQ, 1pc for sample checking is available
0.2mm rainfall measurement used steel stainless tipping bucket rain gauge
Q4. How do you ship the goods and how long does it take to arrive?
0.2mm rainfall measurement used steel stainless tipping bucket rain gauge
A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.

Q5. How to proceed an order ?
0.2mm rainfall measurement used steel stainless tipping bucket rain gauge
A: Firstly let us know your requirements or application.Secondly We quote according to your requirements or our suggestions.Thirdly customer confirms the samples and places deposit for formal order.Fourthly We arrange the production.
0.2mm rainfall measurement used steel stainless tipping bucket rain gauge
Q6. Is it OK to print my logo on the products?

A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
0.2mm rainfall measurement used steel stainless tipping bucket rain gauge
Q7: Do you offer guarantee for the products?

A: Yes, we offer 2-5 years warranty to our products.

Q8: How to deal with the faulty?
0.2mm rainfall measurement used steel stainless tipping bucket rain gauge
A: Firstly, Our products are produced in strict quality control system and the defective rate will be less
than 0.2%.Secondly, during the guarantee period, we will send new one with new order for small quantity. For defective batch products, we will repair them and resend them to you or we can discuss the solution including re-call according to real situation.0.2mm rainfall measurement used steel stainless tipping bucket rain gauge
